| NB-334-C 1000 gallons Anhydrous Ammonia StorageTank 265 psig, ASME |
|
Volume Size Design Pressure Orientation Contents Service Material of Construction Empty Weight Lining Exterior Insulation Code |
1000 gallons 42" OD x 180"OA 265 psig Horizontal Anhydrous Ammonia Storage Carbon Steel 2999 lbs Unpainted & Dehydrate Sand Blast, Prime & Lpg White None ASME Section VIII, Div 1 |
INQUIRE PRICE  Click on drawing to enlarge for printing Refrigeration Tanks |
| DRAWINGS ARE UPDATED TO CURRENT A.S.M.E. DATE FOR NEW ORDERS |
